Deye 12kW 3Ph Inverter & Dyness 14kWh Battery Combo

Deye 12kW 3Ph Inverter & Dyness 14kWh Battery Combo

Deye 12kW 3-Phase Hybrid Inverter + Dyness PowerBrick 14.3kWh Battery Bundle

Experience scalable, reliable, and intelligent energy management with the Deye 12kW 3Ph Inverter & Dyness 14kWh Battery Combo, designed for both residential and light commercial solar setups. This high-performance hybrid energy system integrates solar, battery, grid, and generator sources for seamless power independence, efficiency, and safety.

Bundle Includes:

• Deye 12kW 3-Phase Hybrid Inverter

• Dyness PowerBrick 14.3kWh Lithium-Ion Battery

• WiFi monitoring dongle & current transformer

• Pre-configured for grid-tied, off-grid, or hybrid setups

Deye 12kW 3-Phase Hybrid Inverter Features

• Massive 240A charge/discharge capacity for high-demand loads

• Parallel-ready: up to 10 inverters for scalable energy systems

• Flexible AC coupling for retrofitting existing solar setups

• Multi-source energy management: solar, battery, grid, diesel generator

• Two MPPT trackers with 97.6% max efficiency

• UPS switching <5ms for uninterrupted power

• Handles 100% unbalanced loads

• Advanced safety: arc fault, lightning, overvoltage, reverse polarity, surge protection

• Connectivity: RS485, CAN, RS232 + optional Wi-Fi, 4G, LAN, Bluetooth

• IP65 rated, quiet <55dB operation, compact wall-mounted design

Dyness PowerBrick 14.3kWh Battery Features

• High-performance LiFePO₄ chemistry for stability, longevity, and safety

• Max continuous discharge: 200A / 10kW

• Scalable: connect up to 50 units / 716.8kWh

• Optional 5-second fire suppression for added safety

• Compact and mobile with optional wheels

• Peak-shaving for electricity bill reduction

• Remote monitoring with built-in Wi-Fi and OTA firmware updates

• 10-year warranty for peace of mind

Why Choose the Deye 12kW 3Ph Inverter & Dyness 14kWh Battery Combo?

• Ideal for residential homes, commercial buildings, or off-grid installations

• Hybrid-ready with zero export and load-first modes

• Compatible with Pylontech, LG, BYD, and other lithium battery brands

• Seamlessly integrates energy from PV panels, battery, grid, and generator

• Perfect for retrofits or new builds

• Future-proof design with scalable modular capacity

• Smart monitoring and energy optimization via mobile app or web
