Deye 12kW 3Ph Inverter & HinaESS 14kWh Battery Combo

Deye 12kW 3Ph Inverter & HinaESS 14kWh Battery Combo

Take your energy system to the next level with the Deye 12kW 3Ph Inverter & HinaESS 14kWh Battery Combo—a smart, scalable, and secure hybrid solar solution for residential and commercial use. This bundle offers high efficiency, robust safety, and future-ready expansion, ideal for homes, farms, lodges, and small businesses.

Bundle Includes:

• Deye 12kW 3-Phase Hybrid Inverter (SUN-12K-3PH) with WiFi dongle & current transformer

• HinaESS PowerGem Plus 14.3kWh Lithium Battery

• Full communication ports and monitoring setup

• Wall-mount brackets and optional mobility caster wheels

Deye 12kW 3-Phase Hybrid Inverter Features

• Ultra-Fast Charging/Discharging: Up to 240A

• Flexible Parallel Operation: Connect up to 10 inverters and multiple batteries

• Generator Compatible: Store energy from diesel gensets

• Retrofit Friendly: AC coupling for existing solar systems

• Hybrid Modes: Grid-tied, off-grid, or hybrid operation

• Unbalanced Load Support: Handles 100% unbalanced output across phases

• Battery Compatibility: 48V Li-ion & 40–60V lead-acid

• PV Input: Dual MPPT, supports up to 15.6kW PV power

• Efficiency: 97.6% Max | MPPT >99%

• Safety Protections: Reverse polarity, overcurrent, arc fault, lightning, short circuit, thermal

• Smart Interface: Touchscreen display with <5ms UPS switching

• IP65 Rated: Weatherproof indoor/outdoor installation

• Communication Options: RS485, RS232, CAN, WiFi, GPRS, Bluetooth, 4G, LAN

• Noise & Cooling: <55dB, intelligent air cooling

• Warranty: 5 years (extendable to 10 years)

HinaESS PowerGem Plus 14.3kWh Battery Features

• Usable Capacity: 14.3kWh

• Long Life: ≥8,000 cycles at 0.5C discharge

• Smart BMS: Ensures optimal performance and safety

• Expandable: Connect up to 32 units for larger systems

• Fire Suppression: Built-in safety system

• Installation: Wall-mount with fixed feet or optional caster wheels

• Certifications: CE, UN38.3, IEC62619

• Warranty: 10 years

Key Benefits

• Complete hybrid solar solution: inverter + battery + PV integration

• Scalable & modular for future energy expansion

• Off-grid and generator ready for uninterrupted power

• Smart energy management with TOU (time-of-use) settings

• Safe, reliable, and globally certified

Ideal For

• Homes seeking energy independence

• Lodges, farms, and small businesses needing reliable solar backup

• New solar installations or retrofits

• High-demand areas with unstable grid or frequent load-shedding
