Deye 12kW Inverter & HinaESS 14kWh Battery Solar Kit

Deye 12kW Inverter & HinaESS 14kWh Battery Solar Kit

The Deye 12kW Inverter & HinaESS 14kWh Battery Solar Kit is a complete hybrid solar solution for homes and businesses seeking scalable, reliable, and future-proof energy storage. This bundle includes a 12kW hybrid inverter, a HinaESS 14.3kWh lithium battery, and 12 Hi-MO 7 600W bifacial solar panels—ideal for new installations or retrofits.

Bundle Includes

• 1x 12kW Deye Hybrid Inverter (Max 240A charge/discharge)

• 1x HinaESS 14.3kWh PowerGem Plus Lithium-Ion Battery (8000+ cycles, modular)

• 12x Hi-MO 7 600W Bifacial Solar Panels

• All required cables, brackets, hanging boards, and installation-ready components

Deye Hybrid Inverter Highlights

• Max Charging/Discharging: 240A for fast energy response

• Parallel Capability: Up to 10 inverters and multiple batteries

• Diesel Generator Compatible: Reliable backup power integration

• AC Coupling: Retrofit-friendly for existing systems

• Flexible Modes: Grid-tied, hybrid, off-grid operation with smart management

• UPS Transfer: <5ms switchover for uninterrupted power

• Unbalanced Load Support: Each phase up to 50% rated power

• Touch LCD + IP65 Rating: Outdoor-ready and easy monitoring

• Advanced Protections: DC polarity, AC overcurrent/overvoltage, thermal, PV rapid shutdown, arc fault, lightning, and monitoring

• Communication: WiFi, GPRS, Bluetooth, 4G, LAN (optional), RS485, RS232, CAN

HinaESS 14.3kWh Battery Highlights

• Chemistry: Lithium Iron Phosphate (LFP) with smart BMS

• Rated Capacity: 14.3 kWh, 8000+ cycles at 0.5C

• Safety: Integrated fire suppression system

• Expandable: Up to 32 units; optional caster wheels for mobility

• Dimensions: 900 x 475 x 238 mm | Weight: 112 kg

• Certifications: CE, UN38.3, IEC62619

• Warranty: 10 years

Hi-MO 7 600W Bifacial Solar Panels

• High Efficiency: ~80% bifacial gain, -0.28%/°C temperature coefficient

• Extra Output: Up to 3–4.5% more power vs standard modules

• Durability: 5400Pa front load, 2400Pa back load, hail resistance 25mm/23m/s

• Panel Specs: Max Power 600W | Voc 52.44V | Isc 14.61A | Vmp 44V | Imp 13.75A

• Dimensions: 2278 x 1134 x 30 mm | Weight 31.8 kg | IP68 junction box

• Warranty: Linear with 0.4% annual degradation

Key Benefits

• ✅ Complete Hybrid Solar System: Inverter, battery, and panels included

• ✅ Scalable & Flexible: Add more inverters, batteries, or panels as needed

• ✅ Smart Energy Management: Time-of-use scheduling, load prioritization

• ✅ Reliable Power Anytime: Hybrid, off-grid, or on-grid operation

• ✅ Safe & Durable: Smart BMS, fire suppression option, IP65/IP68-rated components

• ✅ Warranty Protected: 10-year battery warranty, 5-year inverter warranty (extendable to 10 years)

Ideal for residential homes, small businesses, farms, or off-grid setups needing reliable, efficient, and expandable hybrid solar solutions.
