Deye 5kW Inverter & 6kW Battery Solar Kit

Description:
The Deye 5kW Inverter & 6kW Battery Solar Kit is a complete hybrid solar solution designed for homes and small businesses. This smart system combines a high-efficiency inverter, premium lithium battery, and LONGi solar panels to deliver reliable, scalable, and eco-friendly energy independence.

✅ Bundle Includes:

• Deye SUN-5K-SG05LP1-EU-SM2 Hybrid Inverter

• Deye RW-M 6.1-B 6.14kWh LiFePO₄ Battery

• 4 x LONGi LR5-72HTH-570M Monofacial Solar Panels (2.28kWp total)

• Mounting and connection accessories

⚡ Inverter Highlights – Deye 5kW Hybrid

• 97.6% max efficiency | MPPT >99%

• Supports up to 16 units in parallel (on/off-grid)

• High charge/discharge current up to 190A

• AC coupling – retrofit-ready for existing systems

• Smart scheduling with 6 charge/discharge periods

• Diesel generator compatibility for backup power

• Color Touch LCD interface | IP65 weatherproof

• Advanced protections: overvoltage, surge, short circuit

🔋 Battery Highlights – Deye 6.14kWh LiFePO₄

• Safe LiFePO₄ chemistry with 6000+ cycles

• Nominal Voltage: 51.2V | Usable Energy: 5.53kWh

• Expandable: up to 32 batteries in parallel (196kWh max)

• High power output: 150kW peak (2 mins @ 25°C)

• Wall or floor mounting | IP65 rated

• Smart BMS with CAN/RS485, USB firmware updates

• Remote monitoring ready | 10-Year Warranty

☀️ Solar Panel Highlights – 4 x LONGi 570W

• Total Output: 2.28kWp

• Module Efficiency: 22.1%

• Monocrystalline design – excellent low-light performance

• Weather-tested: 5400Pa snow load | 2400Pa wind load

• Warranty: 25-Year Performance | 15-Year Product

✅ Key Benefits:

• Modular & scalable system for future expansion

• Real-time monitoring via LCD & mobile app

• Eco-friendly cobalt-free lithium technology

• IP65-rated inverter & battery for all-weather durability

• Perfect for off-grid, backup, or solar self-consumption
