Deye 5kW Inverter & Battery Solar Kit

Deye 5kW Inverter & Battery Solar Kit

Deye 5kW Hybrid Inverter + 5.3kWh SE-G5.3 LiFePO₄ Battery + 4 x 570W LONGi Solar Panels

Take control of your energy with the Deye 5kW Inverter & Battery Solar Kit—a complete, modular, and high-efficiency hybrid solar solution designed for residential, commercial, and light industrial applications. This bundle delivers reliable power, future-ready scalability, and smart energy management.

Bundle Includes:

• Deye SUN-5K-SG05LP1-EU-SM2 Hybrid Inverter (5kW)

• SE-G5.3 5.32kWh LiFePO₄ Battery

• 4 x LONGi 570W Monofacial Solar Panels

• Mounting accessories and connection cables

Deye 5kW Hybrid Inverter Features

• AC & DC Coupling: Retrofit existing solar systems or install a new hybrid setup

• Max Power: 5,000W continuous, peak up to 2× rated for 10s

• Charge/Discharge Current: 190A max

• Parallel Expansion: Up to 16 inverters (on/off-grid)

• Battery Compatibility: Lithium-ion & Lead-acid (40–60V)

• High Efficiency: 97.6% Max / >99% MPPT

• User Interface: Color touch LCD with IP65 protection

• Generator Integration: Diesel generator support

• Communication Options: Wi-Fi, LAN, RS485/232, CAN, Bluetooth, optional 4G

SE-G5.3 5.32kWh LiFePO₄ Battery Features

• Chemistry: Cobalt-free LiFePO₄ for safety and long life

• Usable Energy: 4.79 kWh

• Rated Capacity: 104Ah @ 51.2V

• Cycle Life: ≥ 6,000 cycles @ 90% DoD

• Discharge Rate: 1C continuous / 150A peak (2 min)

• Scalable: Up to 64 units in parallel

• Smart BMS: Auto SOC balancing with CAN2.0 & RS485 communication

• Mounting Options: Rack, floor, or wall-mounted (3U design)

• Operating Temp: -20°C to 55°C

• Certifications: UN38.3, CE, IEC62619

4 x LONGi 570W Monofacial Solar Panels

• Total Output: 2.28kW

• Efficiency: 22.1%

• Advanced Mono Cells: High performance in low-light conditions

• Durability: 5400Pa front / 2400Pa rear static load rated

• Dimensions: 2278 × 1134 × 35 mm | Weight: 27.5 kg each

• Output Specs: Voc 51.91V | Isc 14.07A | Vmp 43.76V | Imp 13.03A

• Warranty: 15-year product / 25-year performance

Key Benefits

• Complete hybrid energy solution with inverter, battery, and solar panels

• Modular & scalable for future energy expansion

• Off-grid and diesel generator ready for uninterrupted power

• Retrofit-friendly for existing solar systems

• Smart monitoring and firmware updates for real-time control

Ideal For

• Residential homes aiming for energy independence

• Small businesses reducing electricity costs

• Areas with unreliable or unstable grid power

• DIY or professional hybrid solar installations
