Deye 8kW Inverter & 12kWh Battery Combo

Deye 8kW Inverter & 12kWh Battery Combo

Deye 8kW Hybrid Inverter + 2 x 6.14kWh Lithium Battery Bundle (12.28kWh Total)

Take control of your energy with the Deye 8kW Inverter & 12kWh Battery Combo—a scalable, efficient, and intelligent solar energy storage solution for residential and light commercial applications. Perfect for off-grid setups, backup power, and hybrid solar systems.

Bundle Includes:

• Deye 8kW Hybrid Inverter (SUN-8K-SG05LP1-EU-SM2)

• 2 x 6.14kWh Lithium-Ion Batteries (Total 12.28kWh)

• Wall-mount battery brackets & floor supports

• Pre-configured wiring for easy installation

• WiFi/GPRS monitoring dongle

Deye 8kW Hybrid Inverter Features

• High current capacity: 190A charge/discharge for fast, reliable energy

• Parallel-ready: Connect up to 16 units for expanded energy storage

• Compatible with lithium-ion and lead-acid batteries (40–60V)

• AC-coupled for retrofitting existing PV systems

• Generator integration for diesel backup

• Smart battery scheduling: 6 customizable charge/discharge periods

• Touch LCD with IP65 rating for indoor/outdoor use

• Advanced safety: Surge protection, short circuit, thermal, reverse polarity, overvoltage

• Connectivity: WiFi, 4G, Bluetooth, LAN, RS485/RS232/CAN

• UPS capability with <5ms seamless switching

2 x 6.14kWh Lithium Battery Features

• Cobalt-free LiFePO₄ cells for safety, longevity, and high cycle life (>6000 cycles @ 25°C)

• Total capacity: 12.28kWh (2 units, 51.2V nominal)

• Max continuous output: 200A / 10kW

• Expandable: Connect up to 32 batteries for large-scale energy storage

• Compact design: Wall or floor-mounted, IP65-rated enclosure

• Wide operating temperature: -20°C to 55°C

• Built-in BMS for real-time monitoring and protection

• Remote updates & integration via CAN 2.0 & RS485

• Eco-friendly, non-toxic, recyclable materials

Why Choose the Deye 8kW Inverter & 12kWh Battery Combo?

• Ideal for residential homes, farms, lodges, and small commercial buildings

• Perfect for off-grid, backup power, or hybrid solar systems

• Scalable and modular: expand as energy needs grow

• Reduces reliance on grid electricity and saves on bills

• Smart energy management and monitoring via mobile app or web

• Future-proof, reliable, and easy-to-install solution
