Deye 8kW Inverter & 12kWh Battery Solar Kit

Deye 8kW Inverter & 12kWh Battery Solar Kit

The Deye 8kW Inverter & 12kWh Battery Solar Kit is a complete hybrid solar solution for homeowners and small businesses seeking reliable, scalable, and high-performance energy storage. This premium bundle features a robust 8kW Deye hybrid inverter, two 6.14kWh LiFePO₄ batteries, and 8 high-efficiency Hi-MO 7 bifacial solar panels for uninterrupted power—on-grid, off-grid, or backup use.

Bundle Includes

• Deye SUN-(3.6-8)K-SG05LP1-EU-SM2 Hybrid Inverter (8kW)

• 2x Deye RW-M6.1-B Lithium Iron Phosphate Batteries (Total: 12.28kWh)

• 8x Hi-MO 7 600W Bifacial Solar Panels (Total: 4.8kW)

• All required cables, hanging boards, fixed supports, and parallel connectors

Inverter Highlights – Deye 8kW Hybrid

• Max charging/discharging current: 190A for fast, efficient energy flow

• Diesel generator compatible: Ideal for unstable grid regions

• Parallel capability: Up to 16 units (on-grid/off-grid)

• Battery support: Lead-acid & lithium-ion (40–60V)

• AC coupling ready for retrofits

• Touch LCD interface + IP65 outdoor rating

• 6 programmable battery charge/discharge periods

• Efficiency: Max 97.6%, MPPT >99%

• Safety: DC polarity, overcurrent, thermal, surge protection

• Communication: WiFi, 4G, Bluetooth, GPRS, LAN, RS485/RS232, CAN

Battery Highlights – 2x Deye RW-M6.1-B (12.28kWh Total)

• Cobalt-free LiFePO₄ chemistry for safety & durability

• Peak power output: 150kW (2 mins @25°C)

• Scalable: Up to 32 units (max 196kWh)

• Smart monitoring: RS485/CAN integration, remote firmware updates

• Long life: >6000 cycles, 20MWh throughput @70% EOL

• IP65 rated for indoor & outdoor installation

• Mounting: Wall or floor mount

Solar Panels – 8 x Hi-MO 7 600W Bifacial (4.8kW Total)

• Bifacial gain: Up to 80%, ~3% more power vs standard panels

• Degradation: 0.4% per year

• Efficiency: -0.28%/°C temperature coefficient

• Build: 144-cell design, IP68 junction box

• Mechanical load tested: 5400Pa front / 2400Pa rear

• Certifications: IEC, CEI, VDE

• Panel Specs: Voc 52.44V | Isc 14.61A | Vmp 44.00V | Imp 13.75A

• Dimensions: 2278 × 1134 × 30 mm | Weight: 31.8kg

Key Benefits

• ✅ Integrated Hybrid System – inverter, batteries & panels included

• ✅ Scalable & Future-Ready – expand with more batteries or panels

• ✅ Reliable Energy – seamless solar or generator backup power

• ✅ Smart Monitoring – LCD touchscreen + remote app control

• ✅ Eco-Friendly & Durable – clean energy with intelligent BMS

• ✅ Warranty Protected – 10-year product warranty on inverter & batteries

Perfect for residential homes, guest lodges, farms, and small businesses needing dependable backup power and energy independence.

Inverter Documents:
