Luxpower 5kW Inverter & Knyee 5.1kWh Battery Backup Kit

Luxpower 5kW Inverter & Knyee 5.1kWh Battery Backup Kit

⚡ Reliable Hybrid Solar & Backup Power Solution
Includes: Luxpower 5kW Hybrid Inverter + Knyee 5.12kWh LiFePO₄ Battery

Upgrade your home or business energy setup with this intelligent, scalable, and safe solar bundle. Ideal for off-grid, grid-tied, and backup applications, it provides uninterrupted power, easy expansion, and long-term reliability.

🔋 Luxpower 5kW Hybrid Inverter – Features

• Rated Power: 5,000 W continuous / 10,000 VA surge, 10 ms switchover.

• Dual MPPT Inputs: 120–385 V, high-efficiency solar charging.

• Versatile Modes: Supports off-grid, on-grid, backup, and self-consumption.

• Battery Flexibility: Works with lithium or lead-acid batteries.

• Parallel Ready: Connect up to 9 inverters for 50 kW total output.

• Smart Monitoring: Wi-Fi/GPRS remote access and firmware updates.

• Flexible Input: AC, solar, and generator interface.

• Communication Ports: CAN / RS485 compatible with major Li-ion BMS protocols.

• Output: 230 V / 220–110 V split-phase, 50/60 Hz auto-sensing.

• Protection: Overload, short-circuit, thermal, surge; IP20-rated.

• Compact Design: 330 × 504 × 135 mm | 14 kg.

• Warranty: 2 years.

🔋 Knyee 5.12kWh LiFePO₄ Battery – Features

• High-Performance LiFePO₄ Cells: Safe, thermally stable, long-lasting.

• Rated Capacity: 5.12 kWh | 51.2 V | 100 A max charge/discharge.

• Cycle Life: Up to 6,000 cycles @ 80% DoD.

• Smart BMS: Protection against overcharge, discharge, short-circuit, and temperature extremes.

• Expandable: Stack up to 15 batteries in parallel.

• Plug-and-Play Installation: Wall-mounted, compact metal casing.

• Dimensions & Weight: 580 × 480 × 160 mm | 50 kg net.

• Certifications: CE, UN38.3 Class 9.

• Compatible Inverters: Luxpower, Sunsynk, Deye, Growatt, and more.

✅ Bundle Benefits

• Complete hybrid solution for homes, businesses, or off-grid systems.

• Smart remote monitoring and system control via app or web portal.

• Safe, certified, and future-proof energy storage.

• Expandable system up to 50 kW inverter output and 76.8 kWh battery capacity.

• Quick plug-and-play installation for seamless setup.
