Sunsynk 8KW Installation Bundle

SunSynk 8KW Installation Bundle

SunSynk 8.8kW Hybrid Solar Power Bundle with 10.65kWh BYD-Cell Lithium Battery

SunSynk 8KW Installation Bundle
⚡ SunSynk 8.8kW Hybrid Inverter + 10.65kWh BYD-Cell Lithium Battery – Complete Solar Power Solution

Reliable, scalable, and future-ready solar energy for homes, offices, and small businesses. This versatile bundle offers full flexibility — start small or go fully off-grid — with professional installation and a Certificate of Compliance (COC) included for Gauteng.

🔧 What’s Included

• SunSynk 8.8kW Hybrid Inverter

• SunSynk LFP 10.65kWh Wall-Mount Battery (BYD Cells)

• Built-in Wi-Fi Logger & CT Clamp

• SolarMan App Monitoring Access

• Professional Installation & COC (Gauteng only)

⚡ SunSynk 8.8kW Hybrid Inverter – Key Features

• Dual MPPT inputs for optimized solar harvest

• IP65 rated for indoor/outdoor use

• Auto switch between Grid-tied and Off-grid

• Essential & non-essential load outputs

• Zero-export to grid functionality

• Parallel up to 16 units

• Anti-islanding & smart protection systems

• Push-in PV terminals & mobile app monitoring

🔋 SunSynk LFP 10.65kWh Battery – Key Features

• Premium LiFePO₄ BYD-cell technology

• Nominal Voltage: 51.2V | Capacity: 208Ah / 10.65kWh

• Max Power: 10,000W | Cycle Life: 6000+ @ 80% DoD

• 100% Depth of Discharge – full usable energy

• Scalable: Connect up to 8 units (85.2kWh)

• Floor or wall-mounted installation

• Safe, long-lasting, high-performance battery chemistry

📱 Smart Features

• Real-time monitoring via SolarMan App

• Time-of-use & smart load control

• Generator-compatible with prioritised charging

• Programmable modes: On-grid, Off-grid, UPS

🏠 Ideal For

• Residential homes and apartments

• Small business offices and shops

• Backup for load-shedding or unreliable grids

• Off-grid cabins or solar farms

⚙️ Technical Specs – Inverter

• Rated Power: 8,000W | Surge: 12,000W

• Max PV Input: 10,400W | Voltage Range: 125–425VDC

• AC Output: 220V Single Phase, Pure Sine Wave

• Efficiency: 96.5% (Euro) | Weight: 37kg

• Parallel Units: Up to 16

🔋 Battery Specs (per unit)

• Charge/Discharge Current: 100A nominal / 200A max

• Power: 5,000W nominal / 10,000W max

• Dimensions: 550×160×836 mm | Weight: 90kg

• Comms: RS232 / RS485 / CAN | IP Rating: IP20

• Operating Temp: -20°C to 60°C | Max Altitude: 2000m

Inverter Documents:
